Description
Specifications: Model Type: Moving Magnet Complete with Stylus Output Voltage at 1000 Hz, 5cm/sec: 6mV Channel Balance at 1 kHz: 2dB Channel Separation at 1 kHz: 23dB Channel Separation at 15 kHz: 15dB Frequency Range at -3dB: 20-20,000Hz Frequency Response: 20-18.000 Hz +3 / -2 dB Tracking ability at 315Hz at recommended Tracking force: 80µm Compliance, Dynamic, Lateral: 12µm/mN Stylus Type: Spherical Stylus tip radius: R 18µm
Tracking force Range: 2.0-4.0g (20-40 mN) Tracking force: Recommended 3.0g (30mN) Tracking Angle: 20º Internal Impedance: DC resistance 750Ω Internal Inductance: 450mH Recommended Load Resistance: 47kΩ
Recommended Load Capacitance: 200-600pF
Cartridge Colour: Body/Stylus Blue/Blue Cartridge weight: 5g
Original Replacement Stylus: STYDJS
